2B9-210 Goodyear Double Convoluted Air Spring FD 200-19 362 Contitech Modified Car Air Suspension

Подробная информация о продукте:

Место происхождения:	Гуанчжоу, Китай
Фирменное наименование:	GUOMAT
Сертификация:	ISO/Ts16949:2009
Номер модели:	2B6908

Оплата и доставка Условия:

Количество мин заказа:	6 шт
Цена:	$59.9-69.9/pc
Упаковывая детали:	Картонная упаковка или упаковка в соответствии с требованиями клиента
Время доставки:	5-8 рабочих дней
Условия оплаты:	Л/К, Т/Т, западное соединение
Поставка способности:	10 000 в неделю

контакт

Подробное описание продукта

Тип имени:	Воздушные пружинные пакеты подвески	Пружинный материал:	Натуральный каучук
Качество:	100 % протестирован	Гарантия:	12 месяцев
цвет:	Черный	Гудиер:	2Б9-210/578-92-3-202
Гладить:	3,2 дюйма-10,8 дюйма	Firestone:	W01-358-6908
Выделить:	Goodyear double convoluted air spring , Contitech modified car air suspension , FD 200-19 air suspension spring

2B9-210 Goodyear Double Convoluted Air Spring FD 200-19 362 Contitech Modified Car Air Suspension

Product Overview

Air springs for modified cars are specialized components used in vehicle suspension systems to enhance driving experience and vehicle performance. They adjust suspension stiffness and height using air pressure, providing greater flexibility and adaptability compared to traditional steel springs.

Key Benefits

Better adaptation to different road conditions
Reduced vibration and impact for improved comfort
Enhanced stability and handling performance
Adjustable ride height for customized appearance
Compatible with automatic or manual adjustment systems

Product Specifications

Brand

GUOMAT

Model Number

2B6908

Material

Rubber and Steel

Warranty

12 Months

Cross-Reference Part Numbers

Manufacturer	Part Numbers
Goodyear	2B9-210 / 2B 9-210 / 2B9 210
Goodyear Bellows	578-92-202 / 578 92 202 / 57892202
Contitech	64511, FD200-19 362 / FD 200-19 362
Firestone	6908, W01-358-6908 / W01 358 6908 / W013586908

Alternative Manufacturer Equivalents

AUTOMANN	ABSP2B12R-6908
TRIANGLE	4362
TRP	AS69080
WATSON&CHALIN	AS-0035

Technical Data

Mounting Holes/Studs

2 on top and bottom plates

Plate Diameter

6.4 inches (both plates)

Bolt Circle Diameter

3.5 inches

Plate Alignment

Bottom plate parallel to top plate

Internal Bumper

Not included

Minimum Height

3.2 inches

Maximum Height

10.8 inches

Total Stroke

7.6 inches

Goodyear Double Convoluted Air Spring Series

Part Number	Top Plate Holes	Bottom Plate Holes	Top Plate Dia.	Bottom Plate Dia.	Collapsed Height	Flexmember
2B9-229	1	1	6.4	6.4	2.9	578-92-3-211
2B9-245	1	1	6.4	6.4	3.8	578-92-3-202
2B9-218	1	2	6.4	6.4	3.5	578-92-3-206
2B9-230	1	2	6.4	6.4	3.8	578-92-3-202
2B9-246	2	1	6.4	6.4	3.8	578-92-3-211
2B12-304	2	1	9	9	3.4	578-92-3-309
2B12-411	2	1	9	9	3.5	578-92-3-309
2B12-412	2	1	9	9	4.2	578-92-3-309
2B9-244	2	2	6.4	6.4	3.8	578-92-3-202
2B9-252	2	2	6.4	6.4	3.8	578-92-3-206
2B9-254	2	2	6.4	6.4	3.8	578-92-3-206
2B9-265	2	2	6.4	6.4	3.8	578-92-3-206
2B9-266	2	2	6.4	6.4	3.8	578-92-3-208
2B12-410	2	2	9	9	3.5	578-92-3-309
2B12-427	2	2	9	9	3.5	578-92-3-309
2B12-432	2	2	9	9	3.5	578-92-3-309
2B12-434	2	2	9	9	3.5	578-92-3-310
2B12-307	2	2	9	9	3.5	578-92-3-305
2B12-313	2	2	9	9	3.5	578-92-3-309
2B12-317	2	2	9	9	3.5	578-92-3-310
